种类与详细资料/Brief Introduction：

该出产仪器组为10-20ml服食液固态罐装种植线中的通常出产仪器。是由洗瓶、烘干仪器功能一起机和罐装封好一起机所成分，能全自动达到服食液瓶的洗瓶、烘干仪器功能、罐装和封好等姿势，是服食液种植批发厂家更良好的配置出产仪器，几乎适用GMP需求。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

特质/Characteristic：

◆装量计算精度，远离滴漏问题。装灌计算精度不高。High filling accuracy.◆交流变频魔宗变频调速，产生效率可调节，可选装择有所差异的产生效率。Frequency control, production speed is adjustable, you can choose a different production rate.◆一切家用电器开关元件均所采用美国进口知名度高口碑好厂家。All electrical components are imported famous brands.◆自動显示信息运算技能。Automatically countting function.◆的控制选择法国三菱数控系统PLC，抗干扰信号，工做增强。Controlled by Mitsubishi PLC◆耐磨性稳定的，维修日常护理日常护理不便。Stable performance, easy maintenance.◆组装机长相运用SUS304不锈不锈钢板装饰管钢板网作、与货品触及一些运用316L不锈钢板装饰管。组装机全部按GMP追求设置。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

技术水平基本参数/technical parameters：

使用技术参数/Bottle size	10-20ml
产生的能力/Capacity	60-90瓶/分钟的英文/60-90bottles/min
烘干处理湿度/Dryer tempreture	100-300°
工业废水处理流水量/Water wastage	0.5m3/h
过滤水耗量/Purifying water consumption	0.3m3/h
装量精确/Filling precision	≤1%
电源适配器/Voltage	380V/50Hz
电功率/Power	33KW
制造线总长/Dimension	3500×1500×1600mm
