应用场景与百科/Brief Introduction：

全自主注塞泵式膏体酱装灌机就是你司习惯的市场实际需求研发的新服务。此机适用SUS304不锈钢材料注塞泵式计量检测泵来执行装灌，且集自主上盖、自主旋盖、机电工程电子商务为一体式，划算实际，占水泥地面建筑面积小，普遍选用于医药、调味品、药剂、所有、妆容品等业内的气体礼品盒，不符合GMP原则的标准。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

共同点/characteristic：

◆主要包括注塞泵式计量检测泵来执行罐装，适用性不同的浓稠度固体，误差高；泵的组成部分主要包括快接式拆下公司，更加方便擦洗、杀菌消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆注塞泵式记量泵气缸环金属金属木头材质选择业及透明液体有效成分的有差异 选择硅聚氨酯，四氟氯乙烯或某个金属金属木头材质，唯一性公开场合选择瓷器金属金属木头材质。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC抑制系统的，变頻调节，系统自动层次高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不灌装线，手动运算技能。Lack of bottle filling, automatic counting function◆装量修改利于，可是一次修改基本量值溯源检验泵的充填量，也可对於各量值溯源检验泵做出微幅修改；操作步骤简便计算，修改迅速的。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆装灌针头拥有防漏滴设备，充填时前往瓶底装灌，过慢升高，以防止利用气泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆裸机可不适用各种型号的罐子，校准方便，可在间歇间内成功。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆机器按GMP追求设计方案。The machine designed according to the requirements of GMP

新技术叁数/technic parameter：

可用瓶盖品种Size of bottles	20-1000ml（会按照符合要求定制）20-1000 - ml (according to your need）
可用瓶里直经Apply the bottle diameter	¢20-¢150mm
符合盖子规模Apply the lid specifications	¢20-¢70mm
产生的能力 production capacity	四头分装：1000-2500瓶/小時 Four filling head: 1000-2500 bottles per hour 八头分装：2500-4000瓶/h Eight head filling: 2500-4000 bottles per hour 12头包装：4000-6000瓶/几小时 12 head filling: 4000-6000 bottles per hour
装量精度The load error	±1%
旋盖达标率Screw cover percent of pass	≥99%
交流电源power supply	380V，50HZ
耗油率power	3.0KW
供气gas sources	0.4-0.75MPA
速率抑制speed control	直流变频空调调节variable speed
