应用与简价/Brief Introduction：

该线由双曲线式螺栓洗瓶吹干处理一身机、液体液装罐轧盖机二台单人手游包含，包括清晰、变干无菌和装罐封口处3个工作上区，全部可一体化生产的，也可单人手游运用。可顺利完成淋水、mri波清晰、冲水、冲气、吹干处理无菌、蒸发、装罐、理盖、戴盖、轧盖等加工过程。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

优点和缺点/Characteristic：

使用彩超波进行维护清洁及雾气轮流擦拭、远红外耐高温过滤除菌、多头多碇包装与密封等系统。整线联调自动式调整。操作流程单纯简便，建立了机械成系统化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

枝术主要参数/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
不适用规格参数 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(但其中普通运转36Kw)(including normal working 36 kw)
机器人毛重machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
